Finnemanite (original) (raw)
A valid IMA mineral species - grandfathered
About FinnemaniteHide
This section is currently hidden. Click the show button to view.
Colour:
Gray to black; pale olive-green in transmitted light
Name:
Name in honor of Karl Johan Finneman (1880-1953), of Långban, Sweden, who found the first specimen.
This page provides mineralogical data about Finnemanite.
Unique IdentifiersHide
This section is currently hidden. Click the show button to view.
Long-form identifier:
mindat:1:1:1551:2
IMA Classification of FinnemaniteHide
This section is currently hidden. Click the show button to view.
Approved, 'Grandfathered' (first described prior to 1959)
IMA Formula:
Pb5(As3+O3)3Cl
Classification of FinnemaniteHide
This section is currently hidden. Click the show button to view.
4.JB.45
4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
J : Arsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodates
B : Arsenites, antimonites, bismuthites; with additional anions, without H2O
46.1.1.1
46 : ANTIMONITES AND ARSENITES CONTAINING HYDROXYL OR HALOGEN
1 : (AB)m(XO3)pZq
Mineral SymbolsHide
This section is currently hidden. Click the show button to view.
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Fnn | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Pronunciation of FinnemaniteHide
This section is currently hidden. Click the show button to view.
Pronunciation:
| Play | Recorded by | Country |
|---|---|---|
| Sorry, your browser doesn't support HTML5 audio. | Jolyon Ralph | United Kingdom |
Physical Properties of FinnemaniteHide
This section is currently hidden. Click the show button to view.
Transparency:
Translucent, Opaque
Colour:
Gray to black; pale olive-green in transmitted light
Cleavage:
Distinct/Good
On {1011}, distinct
Density:
7.265 g/cm3 (Measured) 7.35 g/cm3 (Calculated)
Optical Data of FinnemaniteHide
This section is currently hidden. Click the show button to view.
RI values:
_n_ω = 2.295 _n_ε = 2.285
δ = 0.010
Image shows birefringence interference colour range (at 30µm thickness)
and does not take into account mineral colouration.
Chemistry of FinnemaniteHide
This section is currently hidden. Click the show button to view.
Mindat Formula:
Pb5(AsO3)3Cl
Crystallography of FinnemaniteHide
This section is currently hidden. Click the show button to view.
Class (H-M):
6/m - Dipyramidal
Cell Parameters:
a = 10.322 Å, c = 7.055 Å
Unit Cell V:
650.96 ų (Calculated from Unit Cell)
Morphology:
Crystals small, distorted, elongated parallel to [0001], exhibiting {1011} and {0001}; as crystalline crusts.
Crystal StructureHide
This section is currently hidden. Click the show button to view.
Load
Unit Cell |Unit Cell Packed
2x2x2 |3x3x3 |4x4x4
Show
Big Balls |Small Balls |Just Balls |Spacefill
Polyhedra Off |Si Polyhedra |All Polyhedra
Remove metal-metal sticks
Display Options
Black Background |White Background
Perspective On |Perspective Off
2D |Stereo |Red-Blue |Red-Cyan
View
CIF File Best |x |y |z |a |b |c
Rotation
Stop |Start
Labels
Console Off |On |Grey |Yellow
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0012024 | Finnemanite | Effenberger H, Pertlik F (1977) Der strukturtyp von finnemanit, Pb5Cl(AsO3)3 Anzeiger der Osterreichische Akademie der Wissenschaften 114 209-211 | 1977 | Langban, Varmland, Sweden | 0 | 293 | |
| 0012044 | Finnemanite | Gabrielson O (1956) The crystal structure of finnemanite Pb5Cl(AsO3)3 Arkiv for Mineralogi och Geologi 2 1-8 | 1956 | Langban, Varmland, Sweden | 0 | 293 | |
| 0015673 | Finnemanite | Effenberger H, Pertlik F (1979) Die kristallstruktur des finnemanits, Pb5Cl(AsO3)3, mit einem vergleich zum strukturtyp des chlorapatits, Ca5Cl(PO4)3 Tschermaks Mineralogische und Petrographische Mitteilungen 26 95-107 | 1979 | Langban, Varmland, Sweden | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder DiffractionHide
This section is currently hidden. Click the show button to view.
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 3.03 Å | (100) |
| 2.88 Å | (90) |
| 3.35 Å | (60) |
| 2.07 Å | (60) |
| 1.957 Å | (50) |
| 1.924 Å | (50) |
| 1.352 Å | (50) |
Geological EnvironmentHide
This section is currently hidden. Click the show button to view.
Type Occurrence of FinnemaniteHide
This section is currently hidden. Click the show button to view.
General Appearance of Type Material:
Place of Conservation of Type Material:
Swedish Museum of Natural History, Stockholm, Sweden.
Geological Setting of Type Material:
Crevices in hematite in a metamorphosed Fe-Mn ore body.
Associated Minerals at Type Locality:
Other Language Names for FinnemaniteHide
This section is currently hidden. Click the show button to view.
Common AssociatesHide
This section is currently hidden. Click the show button to view.
Associated Minerals Based on Photo Data:
Related Minerals - Strunz-mindat GroupingHide
This section is currently hidden. Click the show button to view.
| 4.JB. | Cuyaite | Ca2Mn3+As3+14O24Cl | Mon. m |
|---|---|---|---|
| 4.JB. | Brattforsite | Mn19(AsO 3)12Cl2 | Mon. 2/m : _B_2/b |
| 4.JB.05 | Fetiasite | (Fe3+,Fe2+,Ti)3(As2O5)O2 | Mon. 2/m : _P_21/m |
| 4.JB.10 | Manganarsite | Mn3(As2O4)(OH)4 | Trig. |
| 4.JB.15 | UM1984-09-AsO:ClHMn | Mn10As6O18(OH)Cl | Tet. 4/m m m _(_4/_m_2/_m_2/m ) : _I_41/a c d |
| 4.JB.15 | Magnussonite | Mn2+10(As3+O3)6(OH,Cl)2 | Iso. m_3_m _(_4/_m_32/m ) : I a_3_d |
| 4.JB.20 | Armangite | Mn2+26(AsO3)14(HAsO3)4(CO3) | Trig. 3 : _P_3 |
| 4.JB.25 | Nanlingite | Na(Ca5Li)Mg12(AsO3)2[Fe(AsO3)6]F14 | Trig. 3_m_ _(_32/m ) : R_3_m |
| 4.JB.30 | Asbecasite | Ca3(Ti,Sn4+)Be2(AsO3)6(SiO4)2 | Trig. 3_m_ : _P_3_c_1 |
| 4.JB.35 | Stenhuggarite | CaFeSb(AsO3)2O | Tet. 4/m m m _(_4/_m_2/_m_2/m ) : _I_41/a m d |
| 4.JB.40 | Trigonite | Pb3Mn2+(AsO3)2(HAsO3) | Mon. m |
| 4.JB.50 | Gebhardite | Pb8(As2O5)2OCl6 | Mon. 2/m : _P_21/b |
| 4.JB.55 | Graeserite | Fe3+4Ti3As3+O13(OH) | Mon. 2/m : _B_2/m |
| 4.JB.55 | Tomichite | (V,Fe)4Ti3AsO13(OH) | Mon. 2/m : _P_21/m |
| 4.JB.55 | Derbylite | Fe3+4Ti3Sb3+O13(OH) | Mon. 2/m : _P_21/m |
| 4.JB.60 | Hemloite | (Ti,V3+,Fe3+,Al)12(As3+,Sb3+)2O23(OH) | Tric. 1 : _P_1 |
| 4.JB.65 | Freedite | Cu+Pb8(AsO3)2O3Cl5 | Mon. 2/m : _B_2/m |
| 4.JB.70 | Georgiadesite | Pb4(As3+O3)Cl4(OH) | Mon. 2/m : _P_21/b |
| 4.JB.75 | Szklaryite | ◻Al6BAs3+3O15 | Orth. m m m _(_2/_m_2/_m_2/m ) : P b c m |
| 4.JB.75 | Ekatite | (Fe3+,Fe2+,Zn)12(AsO3)6(AsO3,HSiO4)2(OH)6 | Hex. 6_m_ m : P_63_m c |
| 4.JB.85 | Lepageite | Mn2+3(Fe3+7Fe2+4)O3[Sb3+5As3+8O34] | Tric. 1 : _P_1 |
| 4.JB.90 | Bianchiniite | Ba2(TiV)(As2O5)2OF | Tet. 4/m m m _(_4/_m_2/_m_2/m ) : _I_4/m c m |
Other InformationHide
This section is currently hidden. Click the show button to view.
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for FinnemaniteHide
This section is currently hidden. Click the show button to view.
References for FinnemaniteHide
This section is currently hidden. Click the show button to view.
Reference List:
Localities for FinnemaniteHide
This section is currently hidden. Click the show button to view.
This map shows a selection of localities that have latitude and longitude coordinates recorded. Click on the
symbol to view information about a locality. The symbol next to localities in the list can be used to jump to that position on the map.
Locality ListHide
This section is currently hidden. Click the show button to view.
