Szaibélyite (original) (raw)

A valid IMA mineral species - grandfathered

About SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Colour:

White to light yellow; colourless in transmitted light

Crystal System:

Monoclinic

Name:

Named in 1861 by Karl Ferdinand Peters in honor of Stephen Szaibely (Sjájbely) (1777-1855), mine surveyor of Rézbánya, Hungary, who found the first specimens in what is now the Băiţa Mining District (Baita Bihor), Romania.

Unique IdentifiersHide

This section is currently hidden. Click the show button to view.

Long-form identifier:

mindat:1:1:3857:3

IMA Classification of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Approved, 'Grandfathered' (first described prior to 1959)

Type description reference:

Classification of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

6.BA.15

6 : BORATES
B : Diborates
A : Neso-diborates with double triangles B2(O,OH)5; 2(2D); 2(2D) + OH, etc.

25.2.1.2

25 : ANHYDROUS BORATES CONTAINING HYDROXYL OR HALOGEN
2 : Diborates

9.2.4

9 : Borates
2 : Borates of Be and Mg

Mineral SymbolsHide

This section is currently hidden. Click the show button to view.

As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.

Physical Properties of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Transparency:

Transparent, Translucent

Colour:

White to light yellow; colourless in transmitted light

Density:

2.62 g/cm3 (Measured)

Optical Data of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

RI values:

_n_α = 1.530 - 1.670 _n_β = 1.530 - 1.730 _n_γ = 1.550 - 1.740

δ = 0.020 - 0.070

Image shows birefringence interference colour range (at 30µm thickness)
and does not take into account mineral colouration.

Optical Extinction:

Parallel extinction

Comments:

X ∥ elongation; Z ⊥ flattening.

Chemistry of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Crystallography of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Crystal System:

Monoclinic

Class (H-M):

2/m - Prismatic

Cell Parameters:

a = 12.577(2) Å, b = 10.393(2) Å, c = 3.139(1) Å
β = 95.88(2)°

Ratio:

a:b:c = 1.21 : 1 : 0.302

Unit Cell V:

408.15 ų (Calculated from Unit Cell)

Morphology:

Veinlets or masses with a felted or matted fibrous structure. Nodules, dense or chalky at times. Microscopically presents as minute laths or flattened fibers.

Comment:

Non-standard setting P21/a; Fe-enriched variety (from Internatsional’naya kimberlite pipe): P21/c

X-Ray Powder DiffractionHide

This section is currently hidden. Click the show button to view.

Powder Diffraction Data:

Geological EnvironmentHide

This section is currently hidden. Click the show button to view.

Geological Setting:

Saline and borate deposits.
Magnesian skarns.

Type Occurrence of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

General Appearance of Type Material:

Place of Conservation of Type Material:

Loránd Eötvös University, Budapest, Hungary, E555.

Geological Setting of Type Material:

Synonyms of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Other Language Names for SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Simplified Chinese:硼镁石

Traditional Chinese:硼鎂石

Varieties of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Relationship of Szaibélyite to other SpeciesHide

This section is currently hidden. Click the show button to view.

Common AssociatesHide

This section is currently hidden. Click the show button to view.

Associated Minerals Based on Photo Data:

Related Minerals - Strunz-mindat GroupingHide

This section is currently hidden. Click the show button to view.

Fluorescence of SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Other InformationHide

This section is currently hidden. Click the show button to view.

IR Spectrum:

Kebirnin'ya creek material [cm-1]: 3690w, 3560, 2975w, 2900w, 2760w, 2620sh, 2560w, 2495, 2030w, 1925, 1825w, 1465s, 1405sh, 1388s, 1274s, 1245s, 1223s, 1014, 981, 923, 841, 703s, 679, 623s, 563, 533, 508, 486, 440s, 400s

Notes:

Slowly soluble in acids.

An alteration product of Colemanite, Inyoite, and Hydroboracite (Inder deposits).

Health Risks:

No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.

Internet Links for SzaibélyiteHide

This section is currently hidden. Click the show button to view.

References for SzaibélyiteHide

This section is currently hidden. Click the show button to view.

Reference List:

**Palache, Charles, Berman, Harry, Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Ect. John Wiley and Sons, New York.**pp.375-377

Zubkova, N.V., Pekov, I.V., Chukanov, N.V., Chaikovskiy, I.I., Yapaskurt, V.O., Pushcharovsky, D.Yu. (2020): The new Fe2+-rich variety of szaibélyite and its crystal-chemical peculiarities. Zapiski RMO (Proceedings of the Russian Mineralogical Society): 149(2): 72-79.

Localities for SzaibélyiteHide

This section is currently hidden. Click the show button to view.

This map shows a selection of localities that have latitude and longitude coordinates recorded. Click on the symbol to view information about a locality. The symbol next to localities in the list can be used to jump to that position on the map.

Locality ListHide

This section is currently hidden. Click the show button to view.

- This locality has map coordinates listed. - This locality has estimated coordinates. ⓘ - Click for references and further information on this occurrence. ? - Indicates mineral may be doubtful at this locality. - Good crystals or important locality for species. - World class for species or very significant. (TL) - Type Locality for a valid mineral species. (FRL) - First Recorded Locality for everything else (eg varieties). Struck out - Mineral was erroneously reported from this locality. Faded * - Never found at this locality but inferred to have existed at some point in the past (e.g. from pseudomorphs).

All localities listed without proper references should be considered as questionable.
