(Not recommended) Inception-v3 convolutional neural network

Syntax

Description

Inception-v3 is a convolutional neural network that is 48 layers deep. You can load a pretrained version of the network trained on more than a million images from the ImageNet database [1]. The pretrained network can classify images into 1000 object categories, such as keyboard, mouse, pencil, and many animals. As a result, the network has learned rich feature representations for a wide range of images. The network has an image input size of 299-by-299. For more pretrained networks in MATLAB®, see Pretrained Deep Neural Networks.

[net](#d126e159212) = inceptionv3 returns an Inception-v3 network trained on the ImageNet database.

This function requires the Deep Learning Toolbox™ Model for Inception-v3 Network support package. If this support package is not installed, then the function provides a download link.

example

[net](#d126e159212) = inceptionv3('Weights',`'imagenet'`) returns an Inception-v3 network trained on the ImageNet database. This syntax is equivalent to net = inceptionv3.

[lgraph](#mw%5F99838931-c565-4cfd-aad0-e5512bd5bfb2) = inceptionv3('Weights',`'none'`) returns the untrained Inception-v3 network architecture. The untrained model does not require the support package.

Examples

collapse all

Download and install the Deep Learning Toolbox Model for Inception-v3 Network support package.

Type inceptionv3 at the command line.

If the Deep Learning Toolbox Model for Inception-v3 Network support package is not installed, then the function provides a link to the required support package in the Add-On Explorer. To install the support package, click the link, and then click Install. Check that the installation is successful by typing inceptionv3 at the command line. If the required support package is installed, then the function returns a DAGNetwork object.

ans =

DAGNetwork with properties:

     Layers: [316×1 nnet.cnn.layer.Layer]
Connections: [350×2 table]

Visualize the network using Deep Network Designer.

deepNetworkDesigner(inceptionv3)

Explore other pretrained neural networks in Deep Network Designer by clicking New.

If you need to download a neural network, pause on the desired neural network and click Install to open the Add-On Explorer.

Output Arguments

collapse all

Pretrained Inception-v3 convolutional neural network, returned as aDAGNetwork object.

Untrained Inception-v3 convolutional neural network architecture, returned as a LayerGraph object.

References

[1] ImageNet. http://www.image-net.org.

[2] Szegedy, Christian, Vincent Vanhoucke, Sergey Ioffe, Jon Shlens, and Zbigniew Wojna. “Rethinking the Inception Architecture for Computer Vision.” In 2016 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), 2818–26. Las Vegas, NV, USA: IEEE, 2016. https://doi.org/10.1109/CVPR.2016.308.

Extended Capabilities

expand all

For code generation, you can load the network by using the syntax net = inceptionv3 or by passing the inceptionv3 function to coder.loadDeepLearningNetwork (MATLAB Coder). For example: net = coder.loadDeepLearningNetwork('inceptionv3')

For more information, see Load Pretrained Networks for Code Generation (MATLAB Coder).

The syntax inceptionv3('Weights','none') is not supported for code generation.

Usage notes and limitations:

• For code generation, you can load the network by using the syntaxnet = inceptionv3 or by passing theinceptionv3 function to coder.loadDeepLearningNetwork (GPU Coder). For example: net = coder.loadDeepLearningNetwork('inceptionv3').
  For more information, see Load Pretrained Networks for Code Generation (GPU Coder).
• The syntax inceptionv3('Weights','none') is not supported for GPU code generation.

Version History

Introduced in R2017b

collapse all

inceptionv3 is not recommended. Use the imagePretrainedNetwork function instead and specify"inceptionv3" as the model.

There are no plans to remove support for the inceptionv3 function. However, the imagePretrainedNetwork function has additional functionality that helps with transfer learning workflows. For example, you can specify the number of classes in your data using thenumClasses option, and the function returns a network that is ready for retraining without the need for modification.

The imagePretrainedNetwork function returns the network as a dlnetwork object, which does not store the class names, To get the class names of the pretrained network, use the second output argument of the imagePretrainedNetwork function.

This table shows some typical usages of the inceptionv3 function and how to update your code to use theimagePretrainedNetwork function instead.

The imagePretrainedNetwork returns a dlnetwork object, which also has these advantages:

• dlnetwork objects are a unified data type that supports network building, prediction, built-in training, visualization, compression, verification, and custom training loops.
• dlnetwork objects support a wider range of network architectures that you can create or import from external platforms.
• The trainnet function supports dlnetwork objects, which enables you to easily specify loss functions. You can select from built-in loss functions or specify a custom loss function.
• Training and prediction with dlnetwork objects is typically faster than LayerGraph and trainNetwork workflows.

To train a neural network specified as a dlnetwork object, use the trainnet function.
