Set or get graphics theme

Since R2025a

Syntax

Description

Set Theme

theme([newtheme](#mw%5Fe39f259c-fba5-4899-bccc-6270dd69bf16)) sets the theme of the current figure to the specified new theme, which can be "light","dark", "auto", or aGraphicsTheme object. Parentheses are optional for this syntax when you specify one of the theme names. For example, theme light is the same as theme("light").

Calling this function sets the Theme andThemeMode properties of the figure.

example

theme([fig](#mw%5F4d0401ff-f03f-4974-9912-f68d19fc78b6),[newtheme](#mw%5Fe39f259c-fba5-4899-bccc-6270dd69bf16)) sets the theme of the specified figure.

[gt](#mw%5Fe7c960a0-ff72-4e87-a443-70f4436adb03) = theme(___) sets the theme and returns it as a GraphicsTheme object.

example

Get Theme

[gt](#mw%5Fe7c960a0-ff72-4e87-a443-70f4436adb03) = theme returns the theme of the current figure as a GraphicsTheme object.

[gt](#mw%5Fe7c960a0-ff72-4e87-a443-70f4436adb03) = theme([fig](#mw%5F4d0401ff-f03f-4974-9912-f68d19fc78b6)) returns the theme of the specified figure.

Examples

collapse all

Create a figure and set its theme to "dark" by calling the theme function and returning the GraphicsTheme object as gt. Then create a bar chart in the figure.

fig = figure; gt = theme(fig,"dark"); bar([1 2 3 4; 5 6 7 8])

Figure contains an axes object. The axes object contains 4 objects of type bar.

Change the theme to "light".

Figure contains an axes object. The axes object contains 4 objects of type bar.

Use the GraphicsTheme object, gt, to set the theme.

Figure contains an axes object. The axes object contains 4 objects of type bar.

Input Arguments

collapse all

New theme, specified as "light", "dark","auto", or a GraphicsTheme object.

Target figure, specified as a Figure object or an array ofFigure objects.

Output Arguments

collapse all

Graphics theme object with these properties.

Property	Description
Name	Short description of the theme, returned as 'Light Theme' or'Dark Theme'.
BaseColorStyle	Basic color style of the theme, returned as 'light' or'dark'. This property indicates the overall lightness or darkness of the theme. Query this property when deciding on a color palette for your chart or when writing a ThemeChangedFcn callback.

Version History

Introduced in R2025a
