Mohite (original) (raw)
A valid IMA mineral species
Specific Gravity:
4.86 (Calculated)
Crystal System:
Monoclinic
Name:
Named in 1982 by V. A. Kovalenka, V. S. Malov, T. L. Evstigneeva, and L. S. Vyals in honor of Günter Harald Moh (May 2, 1929 - May 13, 1993), professor at the University of Heidelberg, Germany. A specialist in ore and experimental mineralogy, he performed numerous studies on sulphide systems and first synthesised the compound.
The S analogue of okruginite.
Synthetic Cu2SnS3 apparently has two low-temperature polymorphs: a monoclinic one (Onoda et al., 2000; probably identical to mohite) and a (disordered) stannite-type structure (Chen et al., 1998). A phase transition occurs 780°C, leading to a sphalerite-type structure.
Unique IdentifiersHide
This section is currently hidden. Click the show button to view.
Long-form identifier:
mindat:1:1:2741:6
2ff76dc4-e0d0-482d-a7d8-5bdfc41cf6d1
IMA Classification of MohiteHide
This section is currently hidden. Click the show button to view.
Type description reference:
Classification of MohiteHide
This section is currently hidden. Click the show button to view.
2.CB.15b
2 : SULFIDES and SULFOSALTS (sulfides, selenides, tellurides; arsenides, antimonides, bismuthides; sulfarsenites, sulfantimonites, sulfbismuthites, etc.)
C : Metal Sulfides, M: S = 1: 1 (and similar)
B : With Zn, Fe, Cu, Ag, etc.
2.9.16.1
2 : SULFIDES
9 : AmBnXp, with (m+n):p = 1:1
6.1.2
6 : Sulphosalts - Sulphostannates, Sulphogermanates,Sulpharsenates, Sulphantimonates, Sulphovanadates and Sulphohalides
1 : Sulphostannates and other sulfides containing Sn
Mineral SymbolsHide
This section is currently hidden. Click the show button to view.
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Moh | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Physical Properties of MohiteHide
This section is currently hidden. Click the show button to view.
Hardness:
VHN10=151 - 203 kg/mm2 - Vickers
Density:
4.86 g/cm3 (Calculated)
Optical Data of MohiteHide
This section is currently hidden. Click the show button to view.
Anisotropism:
Distinct, but no color effects
Reflectivity:
| Wavelength | R |
|---|---|
| 460nm | 24.7% |
| 540nm | 25.5% |
| 580nm | 25.7% |
| 660nm | 25.9% |
Graph shows reflectance levels at different wavelengths (in nm). Top of box is 100%. Peak reflectance is 25.9%.
Colour in reflected light:
Gray with a greenish tint
Chemistry of MohiteHide
This section is currently hidden. Click the show button to view.
Crystallography of MohiteHide
This section is currently hidden. Click the show button to view.
Crystal System:
Monoclinic
Cell Parameters:
a = 6.64 Å, b = 11.51 Å, c = 19.93 Å
β = 109.75°
Ratio:
a:b:c = 0.577 : 1 : 1.732
Unit Cell V:
1,433.58 ų (Calculated from Unit Cell)
Morphology:
Grains to 80 microns
Comment:
Space group not determined; c parameter and beta probably incorrect - synthetic, twinned material has space group Cc, a = 6.653(1), b = 11.537(2), c = 6.665(1) Å, β = 109.39(3)° (Onoda et al., 2000).
X-Ray Powder DiffractionHide
This section is currently hidden. Click the show button to view.
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 3.13 Å | (100) |
| 1.920 Å | (70) |
| 2.72 Å | (20) |
| 2.44 Å | (20) |
Geological EnvironmentHide
This section is currently hidden. Click the show button to view.
Geological Setting:
Hydrothermal
Type Occurrence of MohiteHide
This section is currently hidden. Click the show button to view.
General Appearance of Type Material:
Small grains, usually elongated (up to 10 x 50-80 µm) in goldfieldite-famatinite-tetrahedrite ores.
Associated Minerals at Type Locality:
Reference:
Kovalenker, V.A., Malov, V.S., Evstigneeva, T.L., Vyal´sov, L.N. (1982) Mohite, Cu2SnS3, a new sulfide of tin and copper. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 111: 110-114.
Synonyms of MohiteHide
This section is currently hidden. Click the show button to view.
Other Language Names for MohiteHide
This section is currently hidden. Click the show button to view.
Related Minerals - Strunz-mindat GroupingHide
This section is currently hidden. Click the show button to view.
| 2.CB. | Agmantinite | Ag2MnSnS4 | Orth. |
|---|---|---|---|
| 2.CB. | Richardsite | Zn2CuGaS4 | Tet. 42_m_ : I_42_m |
| 2.CB. | Gachingite | Au(Te1-xSex) | Orth. m m m _(_2/_m_2/_m_2/m ) |
| 2.CB. | Tolstykhite | Au3S4Te6 | Tric. 1 : _P_1 |
| 2.CB. | Hanswilkeite | KFeS2 | Mon. 2/m : _B_2/b |
| 2.CB. | Auroselenide | AuSe | Mon. 2/m : _B_2/m |
| 2.CB. | Ruizhongite | (Ag2◻)Pb3Ge2S8 | Iso. 43_m_ : I_43_d |
| 2.CB. | Okruginite | Cu2SnSe3 | Mon. m : B b |
| 2.CB.05a | Coloradoite | HgTe | Iso. 43_m_ : F_43_m |
| 2.CB.05a | Hawleyite | CdS | Iso. 43_m_ : F_43_m |
| 2.CB.05a | Metacinnabar | HgS | Iso. 43_m_ : F_43_m |
| 2.CB.05c | Polhemusite | (Zn,Hg)S | Tet. |
| 2.CB.05b | Sakuraiite | (Cu,Zn,Fe)3(In,Sn)S4 | Iso. |
| 2.CB.05a | Sphalerite | ZnS | Iso. 43_m_ : F_43_m |
| 2.CB.05a | Stilleite | ZnSe | Iso. 43_m_ : F_43_m |
| 2.CB.05a | Tiemannite | HgSe | Iso. 43_m_ : F_43_m |
| 2.CB.05 | UM1998-15-S:CuFeZn | Cu2Fe3Zn5S10 | |
| 2.CB.05a | Rudashevskyite | (Fe,Zn)S | Iso. 43_m_ : F_43_m |
| 2.CB.05a | Ishiharaite | (Cu,Ga,Fe,In,Zn)S | Iso. 43_m_ : F_43_m |
| 2.CB.07a | Shenzhuangite | NiFeS2 | Tet. 42_m_ : I_42_d |
| 2.CB.07a | Unnamed (Cu-Mn-Sn Sulphide) | Cu2MnSnS4 | |
| 2.CB.10a | Chalcopyrite | CuFeS2 | Tet. 42_m_ : I_42_d |
| 2.CB.10a | Eskebornite | CuFeSe2 | Tet. 42_m_ : P_42_c |
| 2.CB.10a | Gallite | CuGaS2 | Tet. 42_m_ : I_42_d |
| 2.CB.10b | Haycockite | Cu4Fe5S8 | Orth. 222 |
| 2.CB.10a | Lenaite | AgFeS2 | Tet. 42_m_ : I_42_d |
| 2.CB.10b | Mooihoekite | Cu9Fe9S16 | Tet. 42_m_ : P_42_m |
| 2.CB.10b | Putoranite | Cu1.1Fe1.2S2 | Iso. m_3_m _(_4/_m_32/m ) : P n_3_m |
| 2.CB.10a | Roquesite | CuInS2 | Tet. 42_m_ : I_42_d |
| 2.CB.10b | Talnakhite | Cu9(Fe,Ni)8S16 | Iso. 43_m_ : I_43_m |
| 2.CB.10a | Laforêtite | AgInS2 | Tet. 42_m_ : I_42_d |
| 2.CB.10a | Unnamed (Cu-Zn-In Sulphide) | CuZn2InS4 | |
| 2.CB.10a | UM1984-30-S:CuFeSn | Cu2Fe2Sn3S7 | |
| 2.CB.10c | Omariniite | Cu8Fe2ZnGe2S12 | Orth. 222 : _I_222 |
| 2.CB.15a | Černýite | Cu2(Cd,Zn,Fe)SnS4 | Tet. 42_m_ : I_42_m |
| 2.CB.15a | Ferrokësterite | Cu2FeSnS4 | Tet. 4 : _I_4 |
| 2.CB.15a | Hocartite | Ag2(Fe2+,Zn)SnS4 | Tet. 42_m_ : I_42_m |
| 2.CB.15a | Idaite | Cu5FeS6 | Hex. |
| 2.CB.15a | Kësterite | Cu2ZnSnS4 | Tet. 4 : _I_4 |
| 2.CB.15a | Kuramite | Cu3SnS4 | Tet. 42_m_ : I_42_m |
| 2.CB.15a | Pirquitasite | Ag2ZnSnS4 | Tet. 4 : _I_4 |
| 2.CB.15a | Stannite | Cu2FeSnS4 | Tet. 42_m_ : I_42_m |
| 2.CB.15c | Stannoidite | Cu+6Cu2+2(Fe2+,Zn)3Sn2S12 | Orth. 222 : _I_222 |
| 2.CB.15a | Velikite | Cu2HgSnS4 | Tet. 4 : _I_4 |
| 2.CB.15c | UM2006-11-S:CuFeGeZn | Cu8(Fe,Zn)3Ge2S12 (?) | |
| 2.CB.17a v | Arsenic-bearing Renierite | Cu11GeAsFe4S16 | |
| 2.CB.20 | Chatkalite | Cu6FeSn2S8 | Tet. 42_m_ : _P_4_m_2 |
| 2.CB.20 | Mawsonite | Cu6Fe2SnS8 | Tet. 42_m_ : _P_4_m_2 |
| 2.CB.30 | Argyropyrite | near Ag2Fe7S11 | |
| 2.CB.30 | Colusite | Cu13VAs3S16 | Iso. 43_m_ : P_43_n |
| 2.CB.30 | Germanite | Cu13Fe2Ge2S16 | Iso. 43_m_ : P_43_n |
| 2.CB.30 | Germanocolusite | Cu26V2(Ge,As)6S32 | Iso. 43_m_ : P_43_m |
| 2.CB.30 | Nekrasovite | Cu26V2(Sn,As,Sb)6S32 | Iso. 43_m_ : P_43_n |
| 2.CB.30 | Stibiocolusite | Cu13V(Sb,Sn,As)3S16 | Iso. 43_m_ : P_43_m |
| 2.CB.30 | Ovamboite | Cu20(Fe,Cu,Zn)6W2Ge6S32 | Iso. 43_m_ : P_43_n |
| 2.CB.30 | Maikainite | Cu20(Fe,Cu)6Mo2Ge6S32 | Iso. m_3_m _(_4/_m_32/m ) |
| 2.CB.30 | Frieseite | Ag2Fe5S8 (?) | |
| 2.CB.35a | Hemusite | Cu6SnMoS8 | Iso. |
| 2.CB.35a | Kiddcreekite | Cu6SnWS8 | Iso. 43_m_ : F_43_m |
| 2.CB.35a | Polkovicite | (Fe,Pb)3(Ge,Fe)1-xS4 | Iso. |
| 2.CB.35a | Renierite | (Cu1+,Zn)11Fe4(Ge4+,As5+)2S16 | Tet. 42_m_ : P_42_c |
| 2.CB.35a | Vinciennite | Cu+7Cu2+3Fe2+2Fe3+2Sn(As,Sb)S16 | Tet. |
| 2.CB.35a | Morozeviczite | (Pb,Fe)3Ge1-xS4 | Iso. |
| 2.CB.35b | Catamarcaite | Cu6GeWS8 | Hex. 6_m_ m : P_63_m c |
| 2.CB.40 | Lautite | CuAsS | Orth. m m m _(_2/_m_2/_m_2/m ) : P n m a |
| 2.CB.42 | Lingbaoite | AgTe3 | Trig. 3_m_ : R_3_m |
| 2.CB.45 | Cadmoselite | CdSe | Hex. 6_m_ m : P_63_m c |
| 2.CB.45 | Greenockite | CdS | Hex. 6_m_ m : P_63_m c |
| 2.CB.45 | Wurtzite | (Zn,Fe)S | Hex. 6_m_ m : P_63_m c |
| 2.CB.45 | Rambergite | MnS | Hex. 6_m_ m : P_63_m c |
| 2.CB.45 | Buseckite | (Fe,Zn,Mn)S | Hex. 6_m_ m : P_63_m c |
| 2.CB.45 | Maletoyvayamite | Au3Se4Te6 | Tric. 1 : _P_1 |
| 2.CB.47 | Murchisite | Cr5S6 | Trig. 3_m_ _(_32/m ) : P_31_c |
| 2.CB.50 | Zincselenide | ZnSe | |
| 2.CB.50 | Wassonite | TiS | Trig. 3_m_ _(_32/m ) : R_3_m |
| 2.CB.52 | Dzhezkazganite | ReMoCu2PbS6 ? | Trig. 3_m_ : R_3_m |
| 2.CB.55a | Cubanite | CuFe2S3 | Orth. m m m _(_2/_m_2/_m_2/m ) |
| 2.CB.55b | Isocubanite | CuFe2S3 | Iso. m_3_m _(_4/_m_32/m ) : F m_3_m |
| 2.CB.60 | Picotpaulite | TlFe2S3 | Orth. m m m _(_2/_m_2/_m_2/m ) : C m c m |
| 2.CB.60 | Raguinite | TlFeS2 | Orth. |
| 2.CB.65 | Argentopyrite | AgFe2S3 | Mon. 2/m |
| 2.CB.65 | Sternbergite | AgFe2S3 | Orth. m m m _(_2/_m_2/_m_2/m ) |
| 2.CB.70 | Sulvanite | Cu3VS4 | Iso. 43_m_ : P_43_m |
| 2.CB.75 | Vulcanite | CuTe | Orth. m m m _(_2/_m_2/_m_2/m ) |
| 2.CB.80 | Empressite | AgTe | Orth. m m m _(_2/_m_2/_m_2/m ) |
| 2.CB.85 | Muthmannite | AuAgTe2 | Mon. 2/m : _P_2/m |
Other InformationHide
This section is currently hidden. Click the show button to view.
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for MohiteHide
This section is currently hidden. Click the show button to view.
References for MohiteHide
This section is currently hidden. Click the show button to view.
Reference List:
**Chen, Xue-an, Wada, Hiroaki, Sato, Akira, Mieno, Masahiro (1998) Synthesis, electrical conductivity, and crystal structure of Cu4Sn7S16 and structure refinement of Cu2SnS3. Journal of Solid State Chemistry, 139. 144-151 doi:10.1006/jssc.1998.7822**[This Cu2SnS3 dimorph has a (disordered) stannite-type structure.]
