Carmeltazite (original) (raw)

A valid IMA mineral species

About CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Colour:

Dark brown to dark green

Crystal System:

Orthorhombic

Name:

The name carmeltazite derives from the type locality, Mt Carmel (“CARMEL”), and from the dominant metals present in the mineral, i.e., titanium, aluminum and zirconium (“TAZ”).

Has an atomic arrangement similar to that observed in a defective spinel structure.

Found in pockets of trapped melt interstitial to, or included in, corundum crystals.

Represents a relatively small group of minerals in which Zr and Ti are located in separate structural sites.

Awarded 'Mineral of the Year' by the IMA-CNMNC in 2018.

Unique IdentifiersHide

This section is currently hidden. Click the show button to view.

Long-form identifier:

mindat:1:1:53294:9

IMA Classification of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Type description reference:

Griffin, William, Gain, Sarah, Bindi, Luca, Toledo, Vered, Cámara, Fernando, Saunders, Martin, O’Reilly, Suzanne (2018) Carmeltazite, ZrAl2Ti4O11, a New Mineral Trapped in Corundum from Volcanic Rocks of Mt Carmel, Northern Israel. Minerals, 8 (12) 601 doi:10.3390/min8120601

Classification of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

4.BB.30

4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
B : Metal: Oxygen = 3:4 and similar
B : With only medium-sized cations

Mineral SymbolsHide

This section is currently hidden. Click the show button to view.

As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.

Physical Properties of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Colour:

Dark brown to dark green

Optical Data of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Bireflectance:

Weak to moderate

Reflectivity:

Graph shows reflectance levels at different wavelengths (in nm). Peak reflectance is 22.9%.
R1 shown in black, R2 shown in red

Internal Reflections:

Absent

Comments:

Dark brown to dark green

Chemistry of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Mindat Formula:

ZrAl2Ti4O11

Crystallography of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Crystal System:

Orthorhombic

Class (H-M):

m m m _(_2/_m_2/_m_2/m ) - Dipyramidal

Cell Parameters:

a = 4.0951(9) Å, b = 5.8123(4) Å, c = 10.0848(7) Å

Ratio:

a:b:c = 0.705 : 1 : 1.735

X-Ray Powder DiffractionHide

This section is currently hidden. Click the show button to view.

Powder Diffraction Data:

Geological EnvironmentHide

This section is currently hidden. Click the show button to view.

Type Occurrence of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

General Appearance of Type Material:

Inclusions in pockets of trapped melt interstitial to, or included in, corundum xenocrysts.

Place of Conservation of Type Material:

Natural History Museum, University of Florence, Italy (3293/I).

Geological Setting of Type Material:

Cretaceous Mt Carmel volcanics of northern Israel.

Associated Minerals at Type Locality:

Reference:

Griffin, William, Gain, Sarah, Bindi, Luca, Toledo, Vered, Cámara, Fernando, Saunders, Martin, O’Reilly, Suzanne (2018) Carmeltazite, ZrAl2Ti4O11, a New Mineral Trapped in Corundum from Volcanic Rocks of Mt Carmel, Northern Israel. Minerals, 8 (12) 601 doi:10.3390/min8120601

Synonyms of CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Other Language Names for CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Common AssociatesHide

This section is currently hidden. Click the show button to view.

Associated Minerals Based on Photo Data:

Related Minerals - Strunz-mindat GroupingHide

This section is currently hidden. Click the show button to view.

Other InformationHide

This section is currently hidden. Click the show button to view.

Health Risks:

No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.

Internet Links for CarmeltaziteHide

This section is currently hidden. Click the show button to view.

References for CarmeltaziteHide

This section is currently hidden. Click the show button to view.

Reference List:

Griffin, William, Gain, Sarah, Bindi, Luca, Toledo, Vered, Cámara, Fernando, Saunders, Martin, O’Reilly, Suzanne (2018) Carmeltazite, ZrAl2Ti4O11, a New Mineral Trapped in Corundum from Volcanic Rocks of Mt Carmel, Northern Israel. Minerals, 8 (12) 601 doi:10.3390/min8120601

Miyawaki, Ritsuro, Hålenius, Ulf, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2019) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) NEWSLETTER 47. European Journal of Mineralogy, 31 (1) 197-202 doi:10.1127/ejm/2019/0031-2839
